Category
Milling machine
Type
mobile column
Made
Model
M-ARX M100
Capacity
10000x4500x1250 mm393,70x177,17x49,21 in
Technical specifications
Metric
Imperial
WORKING CAPACITY
Longitudinal (X)
10000 mm393,70 in
Vertical (Y)
4000 mm157,48 in
Cross RAM (Z)
1250 mm49,21 in
Table (V)
1500 mm59,06 in
Axes support
idrostatica
CNC
Measuring system
righe ottiche
CNC
Heidenhain iTNC530
SPINDLE
Spindle power
(S1) 68 Kw
ATC
Positions
80
FIXING TABLE
Floorspace (LxWxH)
6000x3000x330 mm236,22x118,11x12,99 in
TABLE 1
Surface
1500x1500 mm59,06x59,06 in
Translation
1500 mm59,06 in
Accuracy (B axis)
0,001 °
Capacity
30.000 Kg
PICK UP STATION FOR HEADS
Positions
3
HEAD 1
Type
TUPC
Spindle taper
IS050
A axis
0,001x0,001 °
C axis
0,001x0,001 °
Max speed
4000 Rpm
Max power
68 Kw
Coolant
CTS 40Bar
EXTRA
Total power supply
116 Kw
Floor space
16329x10000x6570 mm642,87x393,70x258,66 in
Tooling included
Testa Prolunga ø160mm SELS / Testa Prolunga ø150 SELS / Testa Prolunga ø150 finitura / Pickup 3 posizioni
High Pressure
40Bar
Filtration unit
SI
Mobile operator platform
SI
Workpiece touch probe
Renishaw
Tool presetter
Laser BLUM
Maintenance & Use books
Yes
Electrical drawings
Yes
CE Certification
Yes
Housing
perimetrale
Chip conveyor
SI
