Technical specifications
Metric
Imperial
WORKING CAPACITY
Centres distance
1000 mm39,37 in
Centres height
200 mm7,87 in
Longitudinal (Z)
1000 mm39,37 in
Max grinding diameter
390 mm15,35 in
TABLE
Stroke
1145 mm45,08 in
Notes
Orientabilità nei due sensi 7 gradi
WHEELHEAD
External spindle power
5,5 Kw
External spindle speed
1420/1650 giri/1'
RIGHT WHEEL
Wheel band thickness
60 mm2,36 in
Max wheel diameter
406 mm15,98 in
Hole diameter
127 mm5,00 in
WORKPIECE HEAD
Taper
4 cm
Notes
Orientabilità nei due sensi 90 gradi
EXTRA
Machine total weight
3700 Kg
Floor space
4370x2200x1800 mm172,05x86,61x70,87 in
Closed steadies
si
Maintenance & Use books
Yes
Electrical drawings
Yes
CE Certification
Yes
Note
Apparecchio per rettifica interni completa di_ porta diamante ribaltabile
Housing
Si
Availability
Pronta
Available in stock
Si
Available under power
Si
